The NSG 6000 consists of an integrated RF signal generator, RF switch and EUT monitoring interfaces. The unit is designed for various EMC applications in the 9 kHz to 6 GHz frequency range. In addition to the generator, the system includes the AM and PM modulators necessary for EMC testing. The NSG 6000 includes 3 freely configurable pulse modulators (1 μs to 200 s) for radar pulse profiles as required e.g. by Ford FMC1278 or VW TL81000. The RF signal can be switched to one of five outputs, where up to five power amplifiers can be connected directly. Different RF switches are supplied for combining amplifiers into two antenna paths or other applications.
NSG 6000 是一套整合了射頻訊號產生器、射頻開關以及被測裝置監控介面的多功能系統。此系統專為涵蓋 9 kHz 至 6 GHz 頻率範圍的各種電磁相容性 (EMC) 應用而設計。除了訊號產生器外，系統還內建了 EMC 測試所需的幅度調變 (AM) 和相位調變 (PM) 調變器。
NSG 6000 配備了 3 組可自由配置的脈衝調變器 (1 μs 至 200 s)，用於產生符合如 Ford FMC1278 或 VW TL81000 等標準規範的雷達脈衝波形。射頻訊號可切換至其中一個輸出端，最多可直接連接五個功率放大器。系統提供多種射頻開關，用於將放大器組合成兩個天線路徑或其他應用。
