IEC/EN 61000-4-6 specifies the design and performance of a range of coupling/decoupling networks (CDNs). Each CDN is specific to the type of cable and the intended signal carried on the cable. The CDN M series is used to inject the RF disturbance on the main line (supply). Teseq offers a solution for two line and three line that can be configured using switch. The presented CDN M0 has a maximum current of 16 A and operating frequency starts from 150 kHz to 230 MHz. Teseq CDN M0 complies fully with the requirements of the standard and provide a simple, reliable and safe method of injecting RF energy into the equipment under test (EUT).

IEC/EN 61000-4-6 規範了一系列耦合／去耦合網路（CDN）的設計與性能要求。每種 CDN 均針對特定的電纜類型及其所傳輸的訊號進行設計。CDN M 系列用於在主電源線（供電線）上注入射頻干擾。Teseq 提供可透過切換開關配置為雙線或三線應用的解決方案。所介紹的 CDN M0 最大電流為 16 A，操作頻率範圍為 150 kHz 至 230 MHz。Teseq 的 CDN M0 完全符合標準規範，能夠為受測設備（EUT）提供一種簡單、可靠且安全的射頻能量注入方式。

• Coupling networks designed for IEC/EN 61000-4-6
• CDN M series for mains applications
• Models with frequency range from 150 kHz to 230 MHz
• Switchable for 2 or 3 Lines application
• Models with 4 mm safety banana sockets

• 專為 IEC/EN 61000-4-6 標準設計的耦合網路
• CDN M 系列，適用於電源線應用
• 頻率範圍 150 kHz 至 230 MHz 型號
• 可切換適用於 2 或 3 線路應用
• 提供 4 mm 安全香蕉插座型號

• IEC / EN Basic Standards : IEC 61000-4-6
• CISPR Standards : CISPR 24
• IEC / EN Generic Standards : EN 61000-6-1 EN 61000-6-2
• IEC / EN Product Standards : IEC 60533 IEC 60601-1-2 IEC 61326
