產品型號 |
頻率 |
功率 |
插入損失 |
隔離度 |
幅度平衡 |
相位平衡 |
駐波比 |
連接器 |
|
（GHz） |
（W） |
（dB，Max.） |
（dB，Min.） |
（±dB，Max.） |
（±°，Max.） |
（Max.） |
||
|
VPD2-0-2000-2-S |
DC~2 |
2 |
6.0±0.5 |
6 |
±0.5 |
- |
1.2 |
SMA |
|
VPD2-0-2400-2-S |
DC~2.4 |
2 |
6.0±0.5 |
6 |
0.5 |
- |
1.2 |
SMA |
|
VPD2-0-3000 |
DC~3 |
2 |
6.0±0.5 |
6 |
±0.5 |
- |
1.2 |
SMA, N |
|
VPD2-0-4000-2-S |
DC~4 |
2 |
6.0±0.5 |
6 |
±0.5 |
- |
1.3 |
SMA |
|
VPD2-0-6000-2-N |
DC~6 |
2 |
6.8 |
5.6 |
0.3 |
±3 |
1.3 |
N |
|
VPD2-0-6000 |
DC~6 |
2 |
7±0.4 |
6 |
±0.5 |
- |
1.25 |
SMA |
|
VPD2-0-8000 |
DC~8 |
2 |
7.2±0.5 |
6 |
±0.5 |
- |
1.4 |
SMA |
|
VPD2-0-10000 |
DC~10 |
0.5 |
6.0±1.5 |
- |
±0.8 |
- |
1.5 |
SMA |
|
VPD2-0-12000-2-S |
DC~12 |
2 |
7.5 |
6 |
±0.5 |
±5 |
1.8 |
SMA |
|
VPD2-0-18000-2-S |
DC~18 |
2 |
7.5 |
6 |
±0.5 |
±5 |
1.9 |
SMA |
|
VPD2-0-40000-2-K |
DC~40 |
2 |
7.5 |
9 |
±0.5 |
±5 |
2.5 |
2.92mm |
|
VPD2-0-50000-1-2 |
DC~50 |
1 |
7.8 |
9 |
±0.8 |
±8 |
2.5 |
2.4mm |
|
VPD2-0-67000-1-V |
DC~67 |
1 |
8 |
9 |
±0.9 |
±10 |
2.5 |
1.85mm |
|
VPD2-5-1000-R5-S |
0.005~1 |
0.5 |
0.8 |
18 |
0.3 |
±3 |
1.3 |
SMA |
|
VPD2-10-100-1-S |
0.01~0.1 |
1 |
1 |
20 |
±0.6 |
±6 |
1.3 |
SMA |
|
VPD2-30-512 |
0.03~0.512 |
300 |
1.4 |
20 |
0.2 |
±2 |
1.2 |
N |
|
VPD2-30-512-S |
0.03~0.512 |
30 |
2.8 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD2-30-3000-2-N |
0.03~3 |
2 |
6.8 |
5.6 |
0.3 |
- |
1.2 |
N |
|
VPD2-30-3000-2-S |
0.03~3 |
2 |
6.8 |
5.6 |
0.3 |
±3 |
1.2 |
SMA |
|
VPD2-52-57 |
0.052~0.057 |
600 |
0.3 |
20 |
0.2 |
±2 |
1.25 |
N |
|
VPD2-70-2700-K1-N |
0.07~2.7 |
100 |
2 |
15 |
0.2 |
±3 |
1.5 |
N |
|
VPD2-80-300-30-S |
0.08~0.3 |
30 |
0.6 |
19 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-100-400 |
0.1~0.4 |
30 |
1 |
22 |
0.2 |
±2 |
1.2 |
N |
|
VPD2-100-500 |
0.1~0.5 |
50 |
0.5 |
20 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD2-100-512 |
0.1~0.512 |
30 |
0.7 |
23 |
0.2 |
±2 |
1.3 |
N |
|
VPD2-100-600 |
0.1~0.6 |
30 |
0.8 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-100-3000 |
0.1~3 |
30 |
2.8 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD2-134-3700 |
0.134~3.7 |
30 |
2.2 |
18 |
0.3 |
±3 |
1.3 |
N |
|
VPD2-138-960 |
0.138~0.96 |
50 |
0.8 |
19 |
0.3 |
±3 |
1.3 |
N |
|
VPD2-150-980 |
0.15~0.98 |
50 |
0.6 |
20 |
0.3 |
±3 |
1.3 |
N |
|
VPD2-200-1000 |
0.2~1 |
30 |
0.6 |
20 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-200-2000 |
0.2~2 |
30 |
0.8 |
20 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD2-200-3000 |
0.2~3 |
30 |
1.5 |
18 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD2-200-4000 |
0.2~4 |
30 |
1.8 |
18 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD2-200-6000 |
0.2~6 |
30 |
2.2 |
18 |
0.3 |
±3 |
1.25 |
SMA, N |
|
VPD2-210-240 |
0.21~0.24 |
50 |
0.3 |
20 |
0.2 |
±2 |
1.2 |
N |
|
VPD2-300-500 |
0.3~0.5 |
50 |
0.3 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-300-600 |
0.3~0.6 |
50 |
0.3 |
20 |
0.2 |
±2 |
1.2 |
N |
|
VPD2-300-900 |
0.3~0.9 |
30 |
0.6 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-300-1000 |
0.3~1 |
300 |
0.3 |
20 |
0.2 |
±2 |
1.25 |
N |
|
VPD2-300-2000-N |
0.3~2 |
50 |
0.8 |
18 |
0.2 |
±3 |
1.3 |
N |
|
VPD2-300-3000 |
0.3~3 |
30 |
0.8 |
20 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD2-300-6000 |
0.3~6 |
30 |
1.6 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD2-336-366 |
0.336~0.366 |
30 |
0.3 |
20 |
0.2 |
±2 |
1.25 |
N |
|
VPD2-380-460 |
0.38~0.46 |
100 |
0.3 |
20 |
0.2 |
±2 |
1.2 |
7/16DIN |
|
VPD2-400-450 |
0.4~0.45 |
100 |
0.4 |
20 |
0.2 |
±2 |
1.2 |
N |
|
VPD2-400-450-K1 |
0.4~0.45 |
50 |
0.2 |
20 |
0.2 |
±2 |
1.2 |
N |
|
VPD2-400-1000 |
0.4~1 |
200 |
0.4 |
20 |
0.2 |
±2 |
1.25 |
N |
|
VPD2-400-6000 |
0.4~6 |
30 |
1.4 |
20 |
0.2 |
±3 |
1.3 |
SMA, N |
|
VPD2-400-8000 |
0.4~8 |
30 |
1.5 |
18 |
0.3 |
±3 |
1.3 |
SMA |
|
VPD2-400-18000 |
0.4~18 |
20 |
1.2 |
12 |
0.3 |
±5 |
1.7 |
SMA |
|
VPD2-500-1000 |
0.5~1 |
30 |
0.4 |
20 |
0.2 |
±2 |
1.2 |
SMA, N |
|
VPD2-500-2000-20-S |
0.5~2 |
20 |
0.5 |
20 |
0.2 |
2 |
1.3 |
SMA |
|
VPD2-500-3000 |
0.5~3 |
30 |
0.8 |
20 |
0.2 |
±3 |
1.25 |
SMA, N |
|
VPD2-500-4000 |
0.5~4 |
30 |
0.8 |
20 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD2-500-6000 |
0.5~6 |
30 |
1.2 |
20 |
0.2 |
±3 |
1.25 |
SMA, N |
|
VPD2-500-8000 |
0.5~8 |
30 |
1.8 |
20 |
0.2 |
±3 |
1.25 |
SMA, N |
|
VPD2-500-18000 |
0.5~18 |
20 |
1.5 |
16 |
0.3 |
±5 |
1.6 |
SMA, N |
|
VPD2-600-2000 |
0.6~2 |
30 |
0.4 |
20 |
0.2 |
±3 |
1.2 |
SMA |
|
VPD2-600-6000 |
0.6~6 |
30 |
1.2 |
20 |
0.2 |
±3 |
1.25 |
SMA, N |
|
VPD2-698-2700 |
0.698~2.7 |
50 |
0.5 |
20 |
±0.2 |
±3 |
1.2 |
N |
|
VPD2-700-2700-30-S |
0.7~2.7 |
30 |
0.5 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-700-2700-K2 |
0.7~2.7 |
200 |
0.5 |
20 |
±0.2 |
±3 |
1.25 |
N |
|
VPD2-700-4000 |
0.7~4 |
30 |
0.6 |
20 |
±0.2 |
±3 |
1.25 |
SMA, N |
|
VPD2-700-4700 |
0.7~4.7 |
30 |
1 |
20 |
0.2 |
±3 |
1.25 |
N |
|
VPD2-700-5000 |
0.7~5 |
30 |
1 |
18 |
0.2 |
4 |
1.3 |
N |
|
VPD2-800-1880 |
0.8~1.88 |
200 |
0.3 |
25 |
0.2 |
2 |
1.25 |
N |
|
VPD2-800-2500 |
0.8~2.5 |
200 |
0.3 |
20 |
0.2 |
3 |
1.25 |
N, 7/16DIN |
|
VPD2-800-2500-S |
0.8~2.5 |
30 |
0.5 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-800-2700-10-S |
0.8~2.7 |
10 |
0.4 |
22 |
±0.2 |
±3 |
1.3 |
SMA |
|
VPD2-800-3000 |
0.8~3 |
30 |
0.6 |
20 |
0.2 |
3 |
1.25 |
SMA, N |
|
VPD2-800-3800 |
0.8~3.8 |
200 |
0.9 |
20 |
±0.2 |
±3 |
1.3 |
7/16DIN |
|
VPD2-800-4000 |
0.8~4 |
30 |
0.8 |
22 |
0.2 |
3 |
1.2 |
SMA |
|
VPD2-950-2150 |
0.95~2.15 |
30 |
0.3 |
20 |
0.2 |
±2 |
1.25 |
SMA, N |
|
VPD2-1000-2000 |
1~2 |
30 |
0.35 |
20 |
0.2 |
±2 |
1.2 |
SMA, N |
|
VPD2-1000-3000-10-S |
1~3 |
10 |
0.5 |
20 |
0.2 |
±3 |
1.2 |
SMA |
|
VPD2-1000-4000-30-S |
1~4 |
30 |
0.4 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-1000-8000-30-S |
1~8 |
30 |
0.9 |
20 |
±0.2 |
±3 |
1.25 |
SMA |
|
VPD2-1000-9000 |
1~9 |
30 |
1.5 |
20 |
0.2 |
±3 |
1.25 |
SMA, N |
|
VPD2-1000-12000-20-S |
1~12 |
20 |
1 |
18 |
0.3 |
±4 |
1.4 |
SMA |
|
VPD2-1000-18000-20-S |
1~18 |
20 |
1.2 |
16 |
0.3 |
±3 |
1.4 |
SMA |
|
VPD2-1000-26500 |
1~26.5 |
20 |
1.2 |
16 |
±0.5 |
±6 |
1.7 |
SMA, 2.92mm |
|
VPD2-1000-40000-20-K |
1~40 |
20 |
2.2 |
15 |
±0.5 |
±8 |
2 |
2.92mm |
|
VPD2-1300-2400 |
1.3~2.4 |
30 |
0.4 |
22 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-1700-5900-30-N |
1.7~5.9 |
30 |
0.5 |
22 |
0.2 |
±3 |
1.2 |
N |
|
VPD2-1700-9000-30-S |
1.7~9 |
30 |
0.8 |
20 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD2-2000-4000 |
2~4 |
30 |
0.4 |
20 |
0.2 |
±2 |
1.25 |
SMA, N |
|
VPD2-2000-6000-30-N |
2~6 |
30 |
0.6 |
22 |
±0.2 |
±3 |
1.25 |
N |
|
VPD2-2000-8000 |
2~8 |
30 |
0.8 |
20 |
0.2 |
±3 |
1.3 |
SMA, N |
|
VPD2-2000-9000-30-S |
2~9 |
30 |
0.6 |
20 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-2000-18000-20-S |
2~18 |
20 |
1.2 |
18 |
0.3 |
±4 |
1.4 |
SMA |
|
VPD2-2000-40000-20-K |
2~40 |
20 |
1.8 |
16 |
0.4 |
±6 |
1.8 |
2.92mm |
|
VPD2-2400-2500-K3-S |
2.4~2.5 |
300 |
0.3 |
30 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-3000-6000-30-S |
3~6 |
30 |
0.4 |
22 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-3000-13000-5-S |
3~13 |
5 |
1.2 |
18 |
±0.3 |
±5 |
1.5 |
SMA |
|
VPD2-4000-5000-30-S |
4~5 |
30 |
0.4 |
22 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-4000-6000 |
4~6 |
30 |
0.4 |
20 |
0.2 |
±2 |
1.2 |
SMA |
|
VPD2-4000-8000 |
4~8 |
30 |
0.5 |
20 |
±0.2 |
±2 |
1.25 |
SMA, N |
|
VPD2-4900-5900 |
4.9~5.9 |
30 |
0.4 |
20 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-5000-12000-20-S |
5~12 |
30 |
0.6 |
18 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD2-6000-18000-20-S |
6~18 |
20 |
0.8 |
18 |
±0.3 |
±4 |
1.4 |
SMA |
|
VPD2-6000-40000-20-K |
6~40 |
20 |
1.3 |
16 |
±0.4 |
±5 |
1.7 |
2.92mm |
|
VPD2-7000-8500-30-S |
7~8.5 |
30 |
0.3 |
20 |
0.2 |
±2 |
1.25 |
SMA |
|
VPD2-7000-9000-30-S |
7~9 |
30 |
0.3 |
20 |
±0.2 |
±2 |
1.25 |
SMA |
|
VPD2-8000-12000-20-S |
8~12 |
20 |
0.5 |
18 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD2-10000-43000 |
10~43 |
20 |
1.3 |
12 |
0.4 |
±5 |
1.6 |
2.92mm |
|
VPD2-10000-43300-20-K |
10~43.3 |
20 |
1.3 |
15 |
±0.4 |
±5 |
1.7 |
2.92mm |
|
VPD2-10700-12750-20-S |
10.7~12.75 |
20 |
0.6 |
18 |
0.3 |
±3 |
1.3 |
SMA |
|
VPD2-18000-26500 |
18~26.5 |
20 |
0.6 |
16 |
0.4 |
±4 |
1.5 |
2.92mm |
|
VPD2-18000-40000-20-K |
18~40 |
20 |
1 |
16 |
0.4 |
±5 |
1.5 |
2.92mm |
|
VPD2-20000-22000-20-K |
20~22 |
20 |
1 |
18 |
±0.4 |
±4 |
1.4 |
2.92mm |
|
VPD2-20000-40000-20-K |
20~40 |
20 |
1.2 |
16 |
±0.4 |
±5 |
1.5 |
2.92mm |
|
VPD2-23100-23300-10-K |
23.1~23.3 |
10 |
0.8 |
18 |
±0.3 |
±3 |
1.5 |
2.92mm |
|
VPD2-24000-43500-20-K |
24~43.5 |
20 |
1.3 |
16 |
±0.4 |
±5 |
1.7 |
2.92mm |
|
VPD2-25500-25600-1-K |
25.5~25.6 |
1 |
0.8 |
18 |
±0.3 |
±3 |
1.5 |
2.92mm |
|
VPD2-26000-40000-20-K |
26~40 |
20 |
1.2 |
16 |
±0.4 |
±4 |
1.5 |
2.92mm |
