產品型號 |
頻率 |
功率 |
插損 |
隔離度 |
幅度平衡 |
相位平衡 |
駐波比 |
連接器 |
|
（GHz） |
（W） |
（dB，Min.） |
（dB，Min.） |
（dB，Max.） |
（°，Max.） |
（Max.） |
||
|
VPD4-0-3000-2-S |
DC~3 |
2 |
12±1.0 |
12 |
±0.6 |
- |
1.3 |
SMA |
|
VPD4-0-6000 |
DC~6 |
2 |
13 |
12 |
±0.8 |
±12 |
1.5 |
SMA，N |
|
VPD4-0-8000-2-S |
DC~8 |
2 |
12±1.5 |
12 |
±0.8 |
- |
1.5 |
SMA |
|
VPD4-0-10000 |
DC~10 |
0.5 |
12±2.0 |
- |
±1.0 |
- |
1.5 |
SMA |
|
VPD4-0-18000-R1-S |
DC~18 |
0.1 |
12±3.0 |
- |
- |
- |
1.8 |
SMA |
|
VPD4-70-2000 |
0.07~2 |
30 |
5.8 |
18 |
0.4 |
±4 |
1.3 |
BNC |
|
VPD4-80-300-30-S |
0.08~0.3 |
30 |
1.4 |
20 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD4-100-400 |
0.1~0.4 |
30 |
1.2 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD4-100-500 |
0.1~0.5 |
30 |
5 |
20 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-100-1000 |
0.1~1 |
30 |
2 |
20 |
0.3 |
±4 |
1.25 |
SMA |
|
VPD4-100-2000 |
0.1~2 |
30 |
3.4 |
20 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-100-3000 |
0.1~3 |
30 |
5.8 |
18 |
0.4 |
±4 |
1.3 |
SMA |
|
VPD4-118-138 |
0.118~0.138 |
500 |
0.5 |
25 |
0.2 |
±2 |
1.2 |
N |
|
VPD4-134-3700 |
0.134~3.7 |
30 |
4.2 |
18 |
0.4 |
±4 |
1.4 |
N |
|
VPD4-138-960 |
0.138~0.96 |
50 |
1.8 |
18 |
0.3 |
±4 |
1.3 |
N |
|
VPD4-150-960 |
0.15~0.96 |
50 |
1.4 |
20 |
0.4 |
±4 |
1.4 |
N |
|
VPD4-200-500 |
0.2~0.5 |
300 |
0.5 |
20 |
0.3 |
±3 |
1.2 |
N |
|
VPD4-200-2000 |
0.2~2 |
30 |
1.8 |
20 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-200-4000 |
0.2~4 |
30 |
3.2 |
18 |
0.4 |
±4 |
1.45 |
SMA |
|
VPD4-200-6000 |
0.2~6 |
30 |
4.2 |
18 |
0.4 |
±4 |
1.4 |
SMA |
|
VPD4-245-255 |
0.245~0.255 |
100 |
0.5 |
25 |
0.2 |
±3 |
1.25 |
SMA |
|
VPD4-250-6000-30-S |
0.25~6 |
30 |
2.8 |
18 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-300-500 |
0.3~0.5 |
50 |
2.8 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD4-300-1000 |
0.3~1 |
300 |
0.4 |
18 |
0.3 |
±3 |
1.25 |
N |
|
VPD4-300-3000 |
0.3~3 |
30 |
1.2 |
20 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-300-6000 |
0.3~6 |
30 |
3.5 |
20 |
0.4 |
±4 |
1.4 |
SMA |
|
VPD4-350-800 |
0.35~0.8 |
50 |
0.5 |
18 |
0.3 |
±3 |
1.25 |
N |
|
VPD4-350-830 |
0.35~0.83 |
150 |
0.8 |
20 |
0.3 |
±3 |
1.3 |
BNC |
|
VPD4-380-460 |
0.38~0.46 |
100 |
0.5 |
20 |
0.3 |
±3 |
1.25 |
7/16DIN |
|
VPD4-400-1000 |
0.4~1 |
30 |
0.5 |
20 |
0.3 |
±3 |
1.25 |
N |
|
VPD4-400-1000-K2 |
0.4~1 |
200 |
0.5 |
20 |
0.3 |
±3 |
1.25 |
N |
|
VPD4-400-4000 |
0.4~4 |
30 |
1.6 |
20 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-400-6000 |
0.4~6 |
30 |
2.4 |
21 |
0.3 |
±4 |
1.3 |
SMA，N |
|
VPD4-450-6000 |
0.45~6 |
30 |
2.4 |
20 |
0.2 |
±4 |
1.3 |
SMA |
|
VPD4-500-1000 |
0.5~1 |
30 |
0.8 |
20 |
0.3 |
±3 |
1.3 |
SMA，N |
|
VPD4-500-2000 |
0.5~2 |
30 |
1 |
20 |
0.3 |
±4 |
1.25 |
SMA |
|
VPD4-500-2000-K2 |
0.5~2 |
200 |
0.7 |
20 |
0.4 |
±4 |
1.25 |
N |
|
VPD4-500-3000 |
0.5~3 |
30 |
1 |
20 |
0.3 |
±4 |
1.2 |
SMA |
|
VPD4-500-4000 |
0.5~4 |
100 |
2 |
18 |
0.3 |
±4 |
1.4 |
SMA，N |
|
VPD4-500-6000 |
0.5~6 |
30 |
2 |
20 |
0.3 |
±4 |
2 |
SMA，N |
|
VPD4-500-8000 |
0.5~8 |
30 |
3.6 |
18 |
0.3 |
±4 |
1.4 |
SMA，N |
|
VPD4-500-18000 |
0.5~18 |
20 |
2.5 |
15 |
±0.4 |
±8 |
2.1 |
SMA |
|
VPD4-600-2000 |
0.6~2 |
30 |
0.8 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD4-600-3000 |
0.6~3 |
50 |
1 |
18 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-600-3600 |
0.6~3.6 |
100 |
2 |
10 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-698-2700 |
0.698~2.7 |
50 |
0.8 |
20 |
±0.4 |
±4 |
1.3 |
N |
|
VPD4-698-4000 |
0.698~4 |
150 |
1.5 |
18 |
0.4 |
±4 |
1.4 |
N |
|
VPD4-700-1100 |
0.7~1.1 |
30 |
0.4 |
22 |
0.3 |
±3 |
1.2 |
SMA |
|
VPD4-700-2000 |
0.7~2 |
30 |
0.6 |
20 |
0.3 |
±3 |
1.2 |
N |
|
VPD4-700-2700 |
0.7~2.7 |
30 |
0.6 |
18 |
0.3 |
±4 |
1.2 |
SMA |
|
VPD4-700-3000 |
0.7~3 |
30 |
0.8 |
20 |
0.3 |
±4 |
1.2 |
SMA |
|
VPD4-700-4000 |
0.7~4 |
30 |
1 |
20 |
±0.4 |
±4 |
1.3 |
N |
|
VPD4-700-4700 |
0.7~4.7 |
30 |
1.6 |
20 |
0.3 |
±4 |
1.3 |
N |
|
VPD4-700-5000 |
0.7~5 |
30 |
2 |
18 |
0.3 |
5 |
1.4 |
N |
|
VPD4-750-1710 |
0.75~1.71 |
30 |
0.4 |
20 |
0.3 |
±3 |
1.2 |
SMA |
|
VPD4-800-2500 |
0.8~2.5 |
30 |
0.6 |
20 |
±0.3 |
±4 |
1.2 |
SMA |
|
VPD4-800-2500-K2 |
0.8~2.5 |
200 |
0.8 |
20 |
0.3 |
4 |
1.3 |
7/16DIN |
|
VPD4-800-2700 |
0.8~2.7 |
30 |
0.6 |
20 |
0.3 |
±4 |
1.2 |
SMA |
|
VPD4-800-4200 |
0.8~4.2 |
200 |
18 |
18 |
0.4 |
±4 |
1.4 |
N |
|
VPD4-850-2150-30-N |
0.85~2.15 |
30 |
0.6 |
22 |
0.3 |
±3 |
1.2 |
N |
|
VPD4-1000-2000 |
1~2 |
30 |
0.8 |
20 |
0.3 |
±3 |
1.3 |
SMA，N |
|
VPD4-1000-4000-30-S |
1~4 |
30 |
0.8 |
20 |
0.3 |
±3 |
1.3 |
SMA |
|
VPD4-1000-6000-30-S |
1~6 |
30 |
1.2 |
20 |
±0.3 |
±4 |
1.3 |
SMA |
|
VPD4-1000-8000-30-S |
1~8 |
30 |
1.5 |
20 |
±0.3 |
±5 |
1.4 |
SMA |
|
VPD4-1000-18000-20-S |
1~18 |
20 |
3 |
16 |
±0.5 |
±6 |
1.6 |
SMA |
|
VPD4-1300-2400 |
1.3~2.4 |
30 |
0.5 |
22 |
0.1 |
±1 |
1.2 |
SMA |
|
VPD4-2000-4000-30-S |
2~4 |
30 |
0.6 |
20 |
0.3 |
±3 |
1.25 |
SMA |
|
VPD4-2000-6000 |
2~6 |
30 |
1 |
20 |
0.3 |
±4 |
1.25 |
SMA，N |
|
VPD4-2000-6000-K4 |
2~6 |
400 |
0.8 |
15 |
±0.5 |
10 |
1.6 |
SMA，N |
|
VPD4-2000-8000 |
2~8 |
30 |
1.5 |
18 |
±0.4 |
±4 |
1.4 |
SMA，N |
|
VPD4-2000-9000-30-S |
2~9 |
30 |
1.8 |
18 |
0.3 |
±4 |
1.4 |
SMA |
|
VPD4-2000-12000 |
2~12 |
20 |
1.6 |
17 |
0.4 |
±5 |
1.5 |
SMA |
|
VPD4-2000-18000-20-S |
2~18 |
20 |
2 |
17 |
0.4 |
±6 |
1.5 |
SMA |
|
VPD4-2000-26500 |
2~26.5 |
20 |
2.6 |
16 |
±0.5 |
±6 |
1.7 |
SMA，2.92mm |
|
VPD4-3400-4800 |
3.4~4.8 |
30 |
0.8 |
25 |
0.3 |
±3 |
1.25 |
SMA，N |
|
VPD4-4000-8000-30-S |
4~8 |
30 |
0.6 |
18 |
0.3 |
±3 |
1.3 |
SMA |
|
VPD4-5500-6000-30-SM |
5.5~6 |
30 |
0.6 |
20 |
0.3 |
±4 |
1.3 |
SMA |
|
VPD4-6000-18000-20-S |
6~18 |
20 |
1.2 |
18 |
±0.4 |
±6 |
1.4 |
SMA |
|
VPD4-7000-9000-30-S |
7~9 |
30 |
0.5 |
18 |
±0.3 |
±3 |
1.3 |
SMA |
|
VPD4-8000-12000-20-S |
8~12 |
20 |
1 |
18 |
0.4 |
±5 |
1.4 |
SMA |
|
VPD4-10000-26500-20-K |
10~26.5 |
20 |
1.5 |
16 |
±0.4 |
±4 |
1.5 |
2.92mm |
|
VPD4-10700-12750-20-S |
10.7~12.75 |
20 |
1 |
18 |
0.4 |
±5 |
1.4 |
SMA |
|
VPD4-10900-12700 |
10.9~12.7 |
20 |
1 |
18 |
0.4 |
±5 |
1.4 |
SMA，N |
|
VPD4-12000-15000-20-S |
12~15 |
20 |
1 |
18 |
0.3 |
±4 |
1.4 |
SMA |
|
VPD4-13750-14500 |
13.75~14.5 |
20 |
1 |
18 |
0.4 |
±5 |
1.4 |
SMA，N |
|
VPD4-15000-17000-20-S |
15~17 |
20 |
1.2 |
18 |
±0.4 |
±4 |
1.4 |
SMA |
|
VPD4-18000-40000-20-K |
18~40 |
20 |
1.6 |
16 |
±0.4 |
±8 |
1.8 |
2.92mm |
|
VPD4-24000-40000-20-K |
24~40 |
20 |
1.6 |
16 |
±0.4 |
±8 |
1.8 |
2.92mm |
|
VPD4-34000-36000-20-K |
34~36 |
20 |
1.5 |
18 |
±0.4 |
±8 |
1.6 |
2.92mm |
