The Compact X-Wing® BiLog® For RF EMC emission and immunity testing in compact anechoic chambers. The combination of BiLog® technology with novel low frequency, folded elements (X-Wing®) allows low frequency power to be efficiently projected forward at 80 MHz without significantly affecting the high frequency elements.

Compact X-Wing® BiLog® 天線
適用於RF EMC（射頻電磁相容）輻射與抗擾度測試，特別適合於緊湊型無響室使用。該天線結合BiLog® 技術與創新的低頻折疊元件（X-Wing®），可在80 MHz時有效將低頻功率向前投射，同時不會顯著影響高頻元件的性能。

• Broadband immunity and emission antenna
• Less than 100 W required above 80 MHz
• Can also be used for emission testing
• Low chamber coupling
• Up to 30% saving in test time
• Excellent symmetry

• 寬頻帶抗擾度與輻射發射天線
• 80 MHz 以上功率需求低於 100 W
• 亦可應用於輻射發射測試
• 腔體耦合低
• 節省測試時間可達 30%
• 優異的對稱性

• IEC / EN Basic Standards : IEC 61000-4-3
• CISPR Standards : CISPR 13 CISPR 14-1 CISPR 16-1-4 CISPR 16-2-3 CISPR 22 CISPR 24 CISPR 32
• IEC / EN Generic Standards : EN 61000-6-1 EN 61000-6-2 EN 61000-6-3 EN 61000-6-4
• IEC / EN Product Standards : IEC 60533 IEC 60601-1-2 IEC 61326
• Automotive Standards : ISO 11452-2
